ABB 216VC62A HESG324442R13 Processor Unit

ABB 216VC62ATechnical specifications​

Rated current (In): 6A (adjustable range: 0.5-6A, C type tripping)

Rated voltage (Ue): 230/400V AC

Breaking capacity (Icn): 6kA (IEC 60898) / 10kA (IEC 60947-2)

Tripping characteristics: B type (3-5In), C type (5-10In), D type (10-14In)

Number of poles: 1P/1P+N/2P/3P/3P+N/4P (216VC62A is 1P)

Wiring method: top/bottom entry, applicable wire section 1-25mm²

Working temperature: -25°C to +60°C

Mechanical life: 20,000 times

Electrical life: 10,000 times

Installation method: DIN rail (35mm)

Purpose:ABB 216VC62A is a miniature circuit breaker​, which belongs to the ABB System Pro M compact series and is designed for ​overload and short-circuit protection of low-voltage power distribution systems. Its core function is to quickly disconnect fault currents and protect the safety of circuits and terminal equipment.

Application:Building power distribution: lighting and socket circuit protection in residential and commercial buildings. Industrial control: small motor and control cabinet power branch circuit protection. Infrastructure: traffic signal system, communication base station power distribution. Renewable energy: solar inverter AC side circuit protection.
