CP216 Key Features
High-frequency signal fidelity
15 kHz bandwidth (±5%) and 80 kHz resonant frequency enable CP216 to accurately capture pressure pulsations (such as combustion oscillations), acceleration sensitivity ≤0.0025 bar/g, and vibration interference resistance is 300% better than traditional strain sensors.
Intrinsically safe explosion-proof
With ATEX Zone 1/2 certification (Ex ib IIC T530), CP216 143-216-000-011 can be directly installed in flammable and explosive environments (such as oil and gas compressors), and mineral insulated cables block arc risks.
Industrial-grade protection design
The fully welded sealed structure (equivalent to IP66) can withstand gamma radiation (10¹⁰ erg/g) and neutron radiation (10¹⁷ n/cm²), and the life of the primary circuit of a nuclear power plant is >10 years.
