X20BM01 key information is summarized
Core Functions
- Power Distribution: Provides 24VDC power to other modules in the X20 system.
- Potential Group Creation: Divides the system into different power zones to meet specific needs.
- I/O Power Management: The internal I/O power supply can be disconnected on the left side of the module, facilitating power control for specific zones.
Technical Parameters
- Input Voltage: 24VDC
- Output Current: 10A
- Dimensions: Single-width, 12.5mm
Main Applications
- Packaging Machinery
- Electronics Manufacturing
- Robotic Control
- Other Industrial Automation Applications, such as Food Processing, Pharmaceuticals, and Printing
Compatible Products: Can be used with power modules (such as the X20PS9400), bus controllers (such as the X20BC0083), and various I/O modules.
Usage Instructions and System Design Key Points
Although the search results did not provide an official, detailed installation manual, based on the available information, there are several key points to note when using and designing an X20 system:
Core Function: The X20BM01 is a core component of the X20 system. It replaces the traditional backplane and is responsible for distributing bus power, bus data, and I/O power throughout the system.
Key Power Grouping: The X20BM01 allows you to segment a large X20 system into several independent potential groups. This is because it can interrupt the internal I/O power supply. For example, you can assign components that require frequent switching (such as solenoid valves) to one power group, while placing controllers and sensors in another, continuously powered group, achieving precise power management.
System Expansion and Protection: When the number of system modules increases (for example, approximately 30 modules), it is usually necessary to add an additional power supply module to ensure stable system operation. To ensure reliability, it is recommended to keep the total system load power below 75% of the power supply module's capacity.
