ABB CP410M 1SBP260181R1001
| Brand | ABB |
| Module Number | CP410M |
| Order Number | 1SBP260181R1001 |
| Unit price | $1999 |
| Country Of Origin | Switzerland and Sweden |
| Weight | 0.55KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 1 |
ABB CP410M is control panel, ABB’s entry-level, ultra-simple HMI, part of the classic CP400 series of monochrome, keypad-operated panels (non-touchscreen).
CP410M Product overview (screen, keys, and architecture):
Display: 160×80 monochrome STN; text display (20 characters × 10 lines); supports text/simple bitmaps only; no dynamic color graphics.
Controls: 16 physical hard keys; no touch overlay.
Communication: RS232/422/485 only; no Ethernet port, USB, or SD card slot.
Protection/Power: IP65 front-panel rating; 24VDC power supply; power consumption <8W.
Programming: Uses the dedicated CP400 Panel Builder tool; projects are incompatible with CP600/CP800 series.
Lifecycle: A classic model that has been discontinued; only limited stock remains on the market.
In addition to the CP400 series, ABB offers the CP600 and CP800 HMI series; the differences between the three are illustrated below:
|
Model Series |
Operation Method |
Screen |
Positioning |
|
CP410M (CP400M) |
16 physical hard keys only; no touch overlay |
3-inch monochrome STN character display (text only) |
Ultra-simple local text-based operator terminal |
|
CP430T/CP450T |
Resistive touch; no large physical buttons
|
Small color TFT screen |
upgraded to a touchscreen version, low-end serial model |
|
CP600/CP600-eCo |
Pure capacitive or resistive touch; a limited number of side function keys |
4.3–15 inch full-color TFT |
Standard General-Purpose Industrial Touch HMI |
|
CP800 |
High-end touch interface, industrial wide-temperature range, redundant network ports |
7–19 inch large HD display |
High-performance panel for production line supervisory systems and DCS integration |
