ABB CTB810
| Brand | ABB |
| Module Number | CTB810 |
| Unit price | $1199 |
| Country Of Origin | Switzerland and Sweden |
| Weight | 0.5KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 1 |
ABB CTB810 is Comm.Terminal Board HN800/CW800 Communications Terminal Board connects to LEFT side of MB810
|
Parameter |
Specification |
|
power voltage |
24V DC |
|
Operation Temperature |
-20℃ to +60℃ |
|
Protection |
IP20 (To be installed in the control cabinet) |
|
WEEE Category |
5. Small Equipment (No External Dimension More Than 50 cm) |
Account Number 88800006406771
Account name Vogi International Trading Co., Limited
(* If the account name exceeds the available space, please continue in the address field.)
SWITF/BIC Code WIHBHKHHXXX
Bank name OCBC Hong Kong Branch
Bank address 161 Queen's Road Central, Central, Hong Kong
Country/Region Hong Kong (China)
Account type Business Account
Bank code 035
Payment method For the payment of goods, please make a FPS/CHATS/SWIFT Payment
Notes Please include the following memo/message to receiver when making a payment: [Buyer Name] [Invoice/Contract Number] [Product]
Core function used in HPC800
As a communication terminal board, CTB810 is installed on the left side of the MB810 substrate and is mainly responsible for handling the connection of communication interfaces.
Core function: It serves as the "communication gateway" for data exchange between the HPC800 controller and external networks (such as engineer stations, operator stations, other PLCs). CTB810 provides physical connection points and converts the signals of the internal bus of MB810 into standard industrial communication interfaces, such as RS-232, RS-485 or Ethernet.
Specific uses:
Protocol conversion and connection: Supports various protocols such as Modbus RTU and Modbus TCP/IP, facilitating connections with upper computers, touch screens, frequency converters, intelligent instruments, etc.
Simplified wiring and maintenance: Concentrates the complex communication cables on the terminal board, making the system layout clearer and facilitating future maintenance and replacement.
