ABB DATX133 Key features
Accurate Position Feedback: Converts fast encoder signals into precise TTL outputs for DCS/PLC control loops.
High Isolation & EMI Immunity: Opto-isolated inputs ensure data integrity in noisy industrial environments.
Modular & Compact Design: 160×160×120 mm form factor with simple DIN-rail mounting eases field installation.
Wide Temperature & Humidity Range: –20 °C to +60 °C, ≤ 95% RH (non-condensing) for reliable operation.
Flexible Encoder Support: Compatible with TTL or NPN encoders, supporting up to 200 kHz pulse rates.
Performance comparison
Model | CPU Performance | Memory Size | I/O Capacity | Recommended Application |
DATX130 | Basic | Small | Low | Compact systems, limited I/Os |
DATX131 | Medium | Moderate | Medium | Standard process control |
DATX133 | High | Large | High | Complex automation & high-speed logic |
Summary：
DATX133 offers high CPU, large memory, and high I/O for complex automation. DATX130 suits compact systems with basic specs. DATX131 fits standard control with medium capacity.
Typical cooperation cases
Germany–Siemens Wind Turbine Factory:
Utilized ABB DATX133 to provide real-time rotor position feedback for generator testing rigs, ensuring precise calibration.
USA–Boeing Aircraft Assembly Line:
Deployed ABB DATX133 in robotics cells to synchronize motor speed and position during fuselage assembly, improving throughput.
India–Bharat Heavy Electricals Power Turbine Workshop:
Employed ABB DATX133 in turbine balancing stations to capture high-speed rotational data, enhancing maintenance accuracy and reducing downtime.
