Bently Nevada 146031-01 Transient Data Interface I/O Module

Bently Nevada 146031-01 Transient Data Interface I/O Module

Brand	Bently Nevada
Module Number	146031-01
Ordering Number	146031-01
Price	$500
Country Of Origin	USA
Weight	0.8kg
Certificate	C/O from the Chamber of Commerce C/Q from the manufacturer
Warranty	12 Months
Inventory Qty	23

Description

Payment & Security

DataSheet Download

Description

Bently Nevada 146031-01 Key parameters
Signal Conditioning & Power
Input Range: Processes DC-coupled signals spanning -10 Vdc to +10 Vdc .
Transducer Excitation: Supplies -24 Vdc to power connected proximity probes .
Buffered Outputs: Includes front-panel coaxial connectors per channel (550 Ω impedance, short-circuit protected) for raw signal diagnostics .
Physical Specifications
Dimensions: 241.3 mm (height) × 24.4 mm (width) × 99.1 mm (depth) / 9.50" × 0.96" × 3.90" .
Weight: 0.20 kg (0.44 lb) .
Slot Occupancy: Fits one full-height rear slot in 3500-series racks .
Environmental & Safety
Operating Temp: -30°C to +65°C (-22°F to +150°F) .
Safety Compliance: Meets intrinsic safety standards (e.g., ATEX/IECEx/CSA) for Zone 2/Division 2 hazardous areas when installed per certified drawings .
Humidity Tolerance: Operates reliably at ≤95% non-condensing humidity .

Payment & Security

Beneficiary's Bank: CITIBANK N.A.
Beneficiary address:Champion Tower,Three Garden Road,Central,Hong Kong
Beneficiary: Vogi International Trading Co., Limited
Account No.: 395714900
Bank Code: 006 Branch Code: 391
Swift Code:CITIHKHX (CITIHKHXXXX * If 11 characters are required)
Payment Term：T/T

DataSheet Download

Bently Nevada 146031-01 Key Features

Integrated Data Bridging Capability
The 146031-01 serves as a critical link between Bently Nevada’s 3500 monitoring racks and the System 1™ machinery management software. It consolidates static data capture as standard, while optional upgrades enable dynamic/transient waveform recording. Unlike standalone units, it merges Rack Interface Module (RIM) functions with communication processor capabilities, eliminating external hardware dependencies .
Ethernet-Driven Industrial Connectivity
Supports 10Base-T/100Base-TX standards via a single RJ-45 port, enabling 10/100 Mbps auto-negotiated data transfer over UTP Category 3–5 cables. Auto-MDIX simplifies cabling, and front-panel LEDs (Link/Activity, Speed) provide real-time status . This flexibility contrasts with fixed-communication modules like the Bently Nevada 140471-01, which prioritize analog I/O handling.
M-Series Monitor Synchronization
Designed to operate in Slot 1 of 3500 racks alongside M-series monitors. It continuously collects steady-state and transient data from these monitors, transmitting it via Ethernet to System 1™ for diagnostics . This seamless integration reduces latency compared to legacy communication processors.
