Bently Nevada 24765-02-01
| Brand | Bently Nevada |
| Module Number | 24765-02-01 |
| Unit price | $5999 |
| Country Of Origin | USA |
| Weight | 2.35KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 1 |
Bentley Nevada 24765-02-01 is Case Expansion Transducer, DC-powered linear variable differential transformer.
24765-02-01, The complete supply form should include LVDT + housing + probe, excluding extension cables.
Linear measurement travel: 50.8 mm (2.00 inch)
Sensitivity: 0.404 V/mm (10.25 V/in)
Power supply: +24 VDC, minimum 30mA
Output signal: DC voltage 0~5V
-3dB bandwidth: 15 Hz (suitable for slow thermal expansion measurement)
Temperature drift coefficient: 0.05 %/℃
Sensor operating temperature: -18 ℃ ~ +71 ℃
Product structure: Metal-sealed rainproof and dustproof housing with built-in pre-tightening return spring; integrated protective cover
Compatible monitoring module: Bently 3500/45. Channels 3 and 4 of this module specifically support LVDT configuration for housing expansion and older 3300 series monitors.
Requires Bently shielded twisted-pair cable (LVDT dedicated cable, do not use coaxial cable for eddy current probes).
Includes original mounting bracket, contact tip, and other mounting accessories.
