EA902 913-902-000-011 Extension Cable

Module Number	EA902
Order Number	913-902-000-011
Unit Price	$1500
Country Of Origin	Switzerland
Weight	1KG
Certificate	C/O from the Chamber of Commerce C/Q from the Manufacturer
Warranty	12 Months
Inventory Qty	3

The EA902 913-902-000-011 is a high-reliability, ATEX/IECEx – certified extension cable for TQ9x2 proximity sensors and IQS900 conditioners, enabling precise vibration/displacement monitoring in explosive atmospheres per API 670

Add to Cart

Submit Inquiry

Description

Payment & Security

Datasheet Download

Description

EA902 Key parameters

Parameter	Specification
Impedance	70 Ω ±1% (at 1 MHz)
Conductor/Shielding	1×0.5mm² silver-plated copper core + double-layer braided copper shielding
Insulation/Sheath	FEP / Flame-retardant PUR (Orange)
Length Tolerance	±2% (Standard 5-meter length)
Operating Temp.	-50°C to +200°C (transient peak) / -40°C to +150°C (continuous)
Bending Radius	7× cable diameter (dynamic) / 4× diameter (static)
Voltage Rating	300V AC RMS (core-to-shield)
Certifications	ATEX/IECEx II 2G Ex ia IIC T6 Gb / II 2D Ex ia IIIC T80°C Db
Compliance	API 670 5th Ed. Annex K, IEC 60079-0/11
Assembly Torque	0.8±0.2 N·m (connector locking torque)
Life Expectancy	>15 years (accelerated aging test at 40°C)

Payment & Security

Beneficiary's Bank: CITIBANK N.A.
Beneficiary address:Champion Tower,Three Garden Road,Central,Hong Kong
Beneficiary: Vogi International Trading Co., Limited
Account No.: 395714900
Bank Code: 006 Branch Code: 391
Swift Code:CITIHKHX (CITIHKHXXXX * If 11 characters are required)
Payment Term：T/T

Datasheet Download

DataSheet Download

EA902 Key Features

Extreme working conditions survivability
EA902 913-902-000-011 has passed the MIL-STD-810G salt spray test (144 hours) and EN 50267-2-1 acid gas corrosion test, and still maintains a 10-year life in the offshore platform H₂S concentration >100ppm area.
Intrinsically safe explosion-proof design
Meeting the highest explosion-proof level of Ex ia IIC, EA902 can be directly connected to the TQ912 sensor in the Zone 1 area, saving more than 30% of the cost of the explosion-proof junction box.
Efficient maintenance architecture
The patented self-locking connector (IP68) supports blind insertion, and with the anti-kink armored structure, the replacement time is <3 minutes, reducing unplanned downtime losses.
