GE IC693MDL645 VME Interface Module
| Brand | GE |
| Module Number | IC693MDL645 |
| Order Number | IC693MDL645 |
| Unit Price | $3000 |
| Country Of Origin | USA |
| Weight | 0.65KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 10 |
GE IC693MDL645 is a high-density 24V DC input module designed for the Series 90-30 PLC system.
IC693MDL645 Key parameters
|
Parameter |
Specification |
|
Module Type |
24V DC Sink/Source Input |
|
Number of Inputs |
16 (High-Density) |
|
Input Voltage |
12-24V DC (Sink/Source) |
|
Current Consumption |
80mA @ 5V DC (Backplane) |
|
Isolation Voltage |
1500V AC (Field to Logic) |
|
Response Time |
1ms (On), 10ms (Off) |
|
Operating Temp. |
-40°C to +70°C |
|
Compatibility |
GE Series 90-30 PLC |
Beneficiary's Bank: CITIBANK N.A.
Beneficiary address:Champion Tower,Three Garden Road,Central,Hong Kong
Beneficiary: Vogi International Trading Co., Limited
Account No.: 395714900
Bank Code: 006 Branch Code: 391
Swift Code:CITIHKHX (CITIHKHXXXX * If 11 characters are required)
Payment Term：T/T
Product Features
The IC693MDL645 offers robust performance with 16 isolated inputs, supporting both sink and source configurations. Its compact design optimizes rack space while maintaining high reliability in harsh environments. The module’s fast response time (1ms) ensures precise real-time control, making the IC693MDL645 ideal for high-speed applications.
IC693MDL645 Comparison
Compared to the IC693MDL640 (32-point input), the IC693MDL645 provides fewer inputs but superior isolation (1500V vs. 1000V) and faster response. The IC693MDL645 is not directly replaceable with the IC693MDL646 (AC input module), but its DC flexibility suits broader voltage ranges. For higher density, the IC693MDL645 may be supplemented with additional modules, though it remains a cost-effective choice for mid-range systems.
IC693MDL645application cases
The IC693MDL645 is extensively deployed in overseas industrial projects, including European automotive assembly lines and Asian power plants. Its durability under extreme temperatures (-40°C to +70°C) ensures reliability in Middle Eastern oil refineries. The module’s compliance with international safety standards (e.g., CE, UL) further drives its adoption in North American water treatment facilities.
