GE IS200DSPXH1C Digital Signal Processor Control Board

GE IS200DSPXH1C Digital Signal Processor Control Board

Brand	GE
Module Number	IS200DSPXH1C
Unit Price	$6000
Country Of Origin	USA
Weight	0.8KG
Certificate	C/O from the Chamber of Commerce C/Q from the Manufacturer
Warranty	12 Months
Inventory Qty	10

IS200DSPXH1C handles critical signal processing and control in Mark VI and EX2100 turbine systems. It processes analog inputs, executes gate and field control logic, monitors stacks and timers, and interfaces with monitoring tools.

Add to Cart

Submit Inquiry

Description

Payment&Security

Description

Function: DSP control board for GE Mark VI / EX2100 turbine systems
Core Processor: 60 MHz digital signal processor
Size: 15.9 cm × 17.8 cm × ~2.5 cm
Operating Temp: –30 °C to +65 °C
Analog I/O: 12 channels, 4–20 mA input, 0–20 mA output
Common Mode Range: ±5 V
Connectors: One backplane P1, two front-panel emulator/monitor ports

Payment&Security

Beneficiary's Bank: CITIBANK N.A.
Beneficiary address:Champion Tower,Three Garden Road,Central,Hong Kong
Beneficiary: Vogi International Trading Co., Limited
Account No.: 395714900
Bank Code: 006 Branch Code: 391
Swift Code:CITIHKHX (CITIHKHXXXX * If 11 characters are required)
Payment Term：T/T

GE IS200DSPXH1C Key features

Executes real-time control algorithms and signal processing
EPLD/ASIC logic for stack overflow detection and watchdog reset
Front-panel port supports DSP emulation and monitoring
No external indicators—reliable diagnostics via connected controller
Surface-mount design ensures compact and rugged performance

INSTALLATION:
Power off VME/EX2100 rack before handling the board
Insert board into the designated slot, ensuring P1 connector seats fully
Tighten front panel screws, connect analog wiring and front-panel cables
Power up rack and verify status via controller diagnostics

Typical cooperation cases：
Europe – Power Generation Racks
Installed in gas turbine Mark VI racks for real-time DSP control and failure monitoring.
Asia – EX2100 Excitation Systems
Used for bridge and motor-regulator control logic in EX2100 series excitation drives.
North America – OEM Drive Panels
Supplies high-speed processing in custom OEM panels with analog signal feedback.
