GE IS200STURH2A IS200STURH2AEC
| Brand | GE |
| Module Number | IS200STURH2A EC |
| Unit price | $2999 |
| Country Of Origin | USA |
| Weight | 0.75KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 1 |
GE IS200STURH2A is called Simplex Primary Turbine Protection Input Terminal Board
IS200STURH2A Structural Layout Description
The product's exterior reveals a multi-layer PCB design featuring industrial-grade SMD components, while the terminals are efficiently arranged along both sides of the unit.
The left side houses four MPU speed signal input terminals.
The right side features two trip relay output terminals and two PT synchronization input terminals.
Located at the bottom is a 37-pin DC connector, which connects to the main control board.
|
Power parameters |
Specification Details |
|
MPU Pulse Range |
2 Hz – 20 kHz |
|
Contact Voltage |
20 V DC |
|
Coil Voltage |
120 V DC / 125 V DC |
|
Output Current |
0.5 A |
Account Number 88800006406771
Account name Vogi International Trading Co., Limited
(* If the account name exceeds the available space, please continue in the address field.)
SWITF/BIC Code WIHBHKHHXXX
Bank name OCBC Hong Kong Branch
Bank address 161 Queen's Road Central, Central, Hong Kong
Country/Region Hong Kong (China)
Account type Business Account
Bank code 035
Payment method For the payment of goods, please make a FPS/CHATS/SWIFT Payment
Notes Please include the following memo/message to receiver when making a payment: [Buyer Name] [Invoice/Contract Number] [Product]
How to determine whether the GE IS200STURH2A product has been installed successfully
Engineers know how to install a product, but how does one determine whether the installation has truly been successful? The purpose of the following guidelines is to provide engineers with the criteria for making this determination:
We can assess the installation across five key dimensions: indicator lights, system diagnostics, signal acquisition, operational response, and the absence of alarms.
- The circuit board must be fully inserted into its backplane slot—neither tilted nor loose—and the front and rear mounting screws must be securely tightened.
Terminal wiring must be firm and secure, free from intermittent connections, wiring errors, or short circuits.
There must be no bent pins, damaged components, or any burnt odors.
The module must not interfere with adjacent modules, and adequate space for heat dissipation must be maintained.
- Upon powering up the system, observe the status of the indicator lights: if the Run indicator (green) remains steadily lit—with no red alarm lights active and no yellow lights flashing—and the relay status indicators toggle correctly in accordance with the system logic, the installation is deemed successful.
III. Within the GE Mark VIe control system interface, navigate to the I/O Configuration or I/O Diagnostics sections; if the IS200STURH2A module is correctly recognized by the system, and its status is displayed as "OK," "Healthy," or "Communicating," the installation is deemed normal.
- If the IS200STURH2A module is able to successfully acquire the MPU speed signal, the PT synchronization signal, and the external protection contact signals, the installation is deemed successful.
- The trip circuit must function correctly, exhibiting neither a failure to trip (refusal to operate) nor an inadvertent trip (false operation).
- A final verification confirming the complete absence of any active alarms signifies a 100% successful installation.
