ABB BB510 3BSE001693R2 Bus Backplane
| Brand | ABB |
| Model Number | BB510 |
| Order Number | 3BSE001693R2 |
| Unit Price | $1500 |
| Country Of Origin | Sweden and Switzerland |
| Weight | 0.75KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 23 |
ABB BB510 3BSE001693R2 is part of a subrack which interconnects inserted electronics PRGXOHV with the help of a communication bus.
ABB BB510 Key parameters
|
Parameter |
Specification |
|
Product Type |
Control_System_Accessory |
|
Technical Information |
BB510 Bus Backplane 12SU |
|
Supply Voltage |
+24V |
|
Categories |
Control Systems → Advant OCS with Master SW → Controllers → Advant Controller 450 |
Account Number 88800006406771
Account name Vogi International Trading Co., Limited
(* If the account name exceeds the available space, please continue in the address field.)
SWITF/BIC Code WIHBHKHHXXX
Bank name OCBC Hong Kong Branch
Bank address 161 Queen's Road Central, Central, Hong Kong
Country/Region Hong Kong (China)
Account type Business Account
Bank code 035
Payment method For the payment of goods, please make a FPS/CHATS/SWIFT Payment
Notes Please include the following memo/message to receiver when making a payment: [Buyer Name] [Invoice/Contract Number] [Product]
ABB BB510 Details
As a Backplane belong to Subrack, Technical Data
Backplane Terminals(Panel layout, see below)
2.1 V and 3.3 V Test of termination voltages
5 V Test of 5 V power supply of the controller subrack
5VBACK Test of the RAM backup voltage 5 V
24 V/A resp. 24 V/B Connection of system power supply 24 V (B used at redundancy)
VBAT/B resp. VBAT/A Connection of NiCd battery (A used to double the battery capacity)
AUXx/y, PFAIL/x Connections not applied
