ABB DI820 3BSE008512R1 Digital Input

Brand	ABB
Module Number	DI820
Ordering Number	3BSE008512R1
Price	$ 600
Country Of Origin	Sweden
Weight	0.2KG
Certificate	C/O from the Chamber of Commerce C/Q from the Manufacturer
Warranty	12 Months
Inventory Qty	10

Description

Payment & Security

DataSheet Download

Description

ABB DI820 Technical specifications

Input type: Dry contact/wet contact compatible, supports 24 V DC, 48 V DC, 120 V AC/DC

Number of input channels: 16 independent channels

Response time: ≤ 3 ms (24 V DC input)

Isolation voltage: Between channels: 500 V AC; Between channels and system: 1500 V AC

Power requirements: Backplane power supply (5 V DC), input loop requires external power supply

Power consumption: Typical power consumption 1.5 W (at 24 V DC input)

Environmental adaptability: Operating temperature: -25°C to +70°C; Humidity: 5-95%

Certification standards: CE, UL, IEC 61131-2, EN 60947

Input voltage range: "0" 0..30 V a.c., 0..20 V d.c.

Input voltage range: "1" 77..130 V a.c., 75..145 Vd.c.

Input impedance:12 kΩ (a.c.) / 39 kΩ (d.c.)

Isolation Individually:isolated channels

Filter times: (digital, selectable) 2, 4, 8, 16 ms

Input frequency range: 47..63 Hz

Current limiting Sensor power can be current limited by the MTU

Maximum field cable length: 200 meters (219 yards) 100 pF/m for a.c., 600 meters (656 yards) for d.c.

Rated insulation voltage:250 V

Dielectric test voltage:2000 V a.c.

Power dissipation Type:2.8 W

Current consumption: +5 V Modulebus 50 mA

Purpose:ABB DI820 is a high-density digital input module designed for ABB AC 800M series controllers. It is used to collect switch signals such as sensor status, button signals, and relay contacts. It is suitable for industrial scenarios that require multi-channel digital monitoring.

Applications:ABB DI820supports high-reliability discrete signal acquisition in power systems such as circuit breaker status monitoring, process industries such as valve position feedback, manufacturing industries such as equipment safety interlocking, and transportation infrastructure such as traffic light control.
