Allen Bradley 1746-OV16 SLC 500 Discrete Output Module
| Brand | Allen Bradley |
| Module Number | 1746-OV16 |
| Unit Price | $200 |
| Country Of Origin | USA |
| Weight | 0.2KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 10 |
Allen Bradley 1746-OV16 is a SLC 500 discrete sinking output module. This module has Sixteen (16) channels that provides a nominal output voltage of 24VDC and 10-50VDC output voltage range.
Allen Bradley 1746-OV16 Specifications:
|
Item |
Specifications |
|
Series |
SLC 500 |
|
Nom Input Voltage |
24VDC |
|
Input Voltage Range |
10-50 VDC |
|
Wiring configuration |
Sink wiring configuration |
|
Backplane current consumption |
0.270 A |
|
Signal delay, max. resistive load |
On = 0.1 ms; Off = 1.0 ms |
|
Continuous current per point |
0.50 A at 30 °C (86 °F); 0.25 A at 60 °C (140 °F) |
|
Continuous current per module |
8.0 A at 30 °C (86 °F); 4.0 A at 60 °C (140 °F) |
|
On-state voltage drop, max |
1.2V at 0.5 A |
|
Surge current per point |
3.0 A for 10 ms |
Beneficiary's Bank: CITIBANK N.A.
Beneficiary address:Champion Tower,Three Garden Road,Central,Hong Kong
Beneficiary: Vogi International Trading Co., Limited
Account No.: 395714900
Bank Code: 006 Branch Code: 391
Swift Code:CITIHKHX (CITIHKHXXXX * If 11 characters are required)
Payment Term：T/T
Allen Bradley 1746-OV16 Key Features
16-Point DC Output Module: Allen Bradley 1746-OV16 is a digital output module with 16 points, designed to control DC-powered devices. Each output on the Allen Bradley 1746-OV16 can handle loads like solenoids, relays, or lamps.
Compatible with SLC 500 Systems: Allen Bradley 1746-OV16 works directly with SLC 500 series chassis and processors. This makes Allen Bradley 1746-OV16 a reliable choice for expanding digital output capacity in automation systems.
Sourcing Output Type: Allen Bradley 1746-OV16 uses a sourcing (positive logic) output configuration. This ensures that the Allen Bradley 1746-OV16 can deliver current to loads when the output is turned on.
LED Status Indicators: Each point on the Allen Bradley 1746-OV16 has an LED indicator, making it easy to monitor output status during operation. This feature helps users quickly detect and troubleshoot issues.
Typical cooperation cases
Controlling Conveyor Belt Systems: Allen Bradley 1746-OV16 is often used to drive actuators and relays in conveyor belt applications. In this setup, the Allen Bradley 1746-OV16 sends signals to start, stop, or change the direction of motors.
Packaging Machine Output Control: In automated packaging lines, the Allen Bradley 1746-OV16 works with SLC 500 controllers to trigger devices like labelers, cutters, or ejectors. The Allen Bradley 1746-OV16 helps control output timing precisely.
Automated Lighting in Production Areas: Allen Bradley 1746-OV16 is used to switch lights or indicators on and off during production. For example, the Allen Bradley 1746-OV16 may control warning lights based on sensor feedback.
Output Interface for Remote I/O Panels: When building distributed control panels, the Allen Bradley 1746-OV16 can serve as the output module in a remote I/O rack. In this case, the Allen Bradley 1746-OV16 activates field devices based on central controller signals.
