CI186 VMD-186-020-AT-CA-S
| Brand | VIBRO-METER MEGGITT |
| Module Number | CI186 |
| Order Number |
VMD-186-020-CT-CA-S VMD-186-020-AT-CA-S |
| Unit price | $999 （just a number） |
| Country Of Origin | UK(Germany Switzerland) |
| Weight | 1.5KG |
| Warranty | 12 Months |
| Inventory Qty | 10 Available |
VIBRO METER(Meggitt) CI186 is Accelerometer can be loop powered and dual output, it is for PLC Interface and data collection
CI186 Its most notable feature is an integrated dual-output design, which combines acceleration sensing with signal conditioning. It provides simultaneous outputs—a 4–20 mA standard industrial signal representing vibration velocity (RMS) and an AC dynamic signal representing vibration acceleration—facilitating easy integration with PLCs, DCSs, or dedicated vibration monitoring systems.
Below is a brief overview of some information regarding technical specifications.
Current Output: 4-20mA proportional to RMS velocity (mm/s)
AC Output: AC voltage proportional to acceleration (g)
Frequency Response: 2 Hz to 1 kHz ±10%
-3 dB at 0.8Hz for AC output
Dynamic Range: 30g peak for 100mV/g: 60g peak for 50mV/g
Mounted Resonance: 5 kHz min
Bias Voltage (AC output) : 3 Volts
Isolation: Base isolated
Operating Temp Range: -25 to 90 ºC
