GE IC694MDL646
| Brand | GE |
| Module Number | IC694MDL646 |
| Unit price | $599 |
| Country Of Origin | USA |
| Weight | 0.75KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 1 |
GE IC694MDL646 is 24vdc 16-point pos neg logic input module
|
Parameter |
Specification |
|
Number of input points |
16 |
|
Nominal Voltage |
24V DC |
|
Input Voltage Range |
0-30 VDC |
|
Conduction state |
Voltage: 11.5 - 30V DC; Current: Minimum 3.2 mA |
Account Number 88800006406771
Account name Vogi International Trading Co., Limited
(* If the account name exceeds the available space, please continue in the address field.)
SWITF/BIC Code WIHBHKHHXXX
Bank name OCBC Hong Kong Branch
Bank address 161 Queen's Road Central, Central, Hong Kong
Country/Region Hong Kong (China)
Account type Business Account
Bank code 035
Payment method For the payment of goods, please make a FPS/CHATS/SWIFT Payment
Notes Please include the following memo/message to receiver when making a payment: [Buyer Name] [Invoice/Contract Number] [Product]
Advantage Analysis
IC694MDL646 has some features as below:
Superior response speed: The typical response time of 1ms is outstanding among similar modules, making it highly suitable for scenarios requiring rapid signal acquisition, such as high-speed counting, positioning control, or emergency stop signal processing.
Flexible and universal wiring: It supports both positive logic and negative logic, meaning it can be compatible with most NPN and PNP type sensors available on the market, without the need for additional adaptations. Its application scope is very wide.
High anti-interference and reliability: Utilizing optocoupler isolation technology, the isolation voltage can reach up to 1500V, effectively blocking electrical noise from the field side. At the same time, it has 15G shock resistance and wide temperature operating capability, making it suitable for long-term stable operation in industrial environments.
State visualization is convenient: Each of the 16 input channels has an independent green LED indicator light. On-site personnel can clearly determine whether the sensor signal has successfully reached the module at a glance, greatly facilitating debugging and fault troubleshooting.
And here is the comparison between IC694MDL646 and others input module
|
Model number |
Type |
Input point |
Key characters |
|
IC694MDL646 |
Pure input |
16 |
24V DC, selectable for positive/negative logic, 1ms high speed |
|
IC694MDL655 |
Pure input |
32 |
24V DC, selectable for positive/negative logic, 1ms high speed |
|
IC694MDL660 |
Pure input |
32 |
24V DC, requires a specific terminal block to be used in conjunction with it. |
|
IC694MDL654 |
Pure input |
32 |
5/12V DC TTL level, used for connecting differential signal devices |
|
IC694MDL930 |
Mixed I/O |
12/24V DC:8 in /8 out |
The same module has both input and output functions |
