GE IC694MDL732
| Brand | GE |
| Module Number | IC694MDL732 |
| Unit price | $599 |
| Country Of Origin | USA |
| Weight | 0.5KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 1 |
GE IC694MDL732 is output module, 12/24Volt DC positive logic 0.5A 8pt.
There are a total of 8 output points, designed with a single group of common terminals.
It belongs to positive logic, source-type output (sourcing), providing current from the common positive power supply terminal to the load.
Connection method
The load is connected between the module output terminal and the negative terminal of the power supply.
The working power supply of the field equipment needs to be provided by the user externally.
The applicable loads can drive various load equipment such as motor starters, solenoid valves, and indicator lights.
Status indication and protection
Each output point has an independent LED indicator light to display the on-off status.
The module itself does not come with a fuse.
Appearance and installation
The blue label on the tag indicates that it is a low-voltage module.
IC694MDL732 can be installed in any I/O slot of the RX3i system.
Account Number 88800006406771
Account name Vogi International Trading Co., Limited
(* If the account name exceeds the available space, please continue in the address field.)
SWITF/BIC Code WIHBHKHHXXX
Bank name OCBC Hong Kong Branch
Bank address 161 Queen's Road Central, Central, Hong Kong
Country/Region Hong Kong (China)
Account type Business Account
Bank code 035
Payment method For the payment of goods, please make a FPS/CHATS/SWIFT Payment
Notes Please include the following memo/message to receiver when making a payment: [Buyer Name] [Invoice/Contract Number] [Product]
Specific application factory of IC694MDL732
Automobile manufacturing (complete vehicles / components)
Food and Beverage / Packaging
General Machinery / Equipment Manufacturing
Logistics / Warehouse Automation
Water Treatment / Environmental Protection
Metallurgy / Steel Industry
Electricity / Energy
The Real case for IC694MDL732
Small material sorting machine
Configuration: RX3i small system + MDL732 Control
Cylinder feeding, stop block, air suction claw
Positive/negative rotation of belt/drum (via intermediate relay)
Positional indication / Full material / Fault indicator light
Features: Exactly 8 points meet the requirements of small machines, economical and compact
