ABB 5SHX2645L0004 3BHL000389P0104
| Brand | ABB |
| Module Number | 5SHX2645L0004 |
| Order Number | 3BHL000389P0104 |
| Unit price | $6599 |
| Country Of Origin | Switzerland and Sweden |
| Weight | 1.5KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 5 |
ABB 5SHX2645L0004 is IGCT module and used to Medium and high voltage high-power converters and grid control equipment.
ABB 5SHX2645L0004 is used to ACS6000 series for Rolling mills, mine hoists, fans and pumps. It also reduces the need for series or parallel connections, resulting in a simpler and more reliable system with low thermal resistance and a long lifespan—capable of operating for over 20 years.
IGCT = The high voltage and high power capacity of a GTO + The fully controllable flexibility of an IGBT + Hard drive operation without a snubber circuit.
What is the different between IGBT and IGCT
|
Parameters |
IGCT(5SHX2645L0004) |
IGBT(4.5kv 1200A) |
|
Voltage Rating |
4.5kV / 6.5kV |
1.7kV / 3.3kV / 4.5kV |
|
Current Rating |
1000–4000A |
1200–3000A |
|
Switching Frequency |
1–10kHz |
10–50kHz |
|
Conduction Loss |
Extremely Low |
Relatively High |
|
Short-Circuit Capability |
Strong (Withstands 4–6 times Rated Current; Protection within ≤2μs) |
Relatively Weak (Typically 2–3 times Rated Current; Requires Rapid Detection) |
|
Gate Drive Complexity |
Fiber-Optic Drive; Requires Dedicated Power Supply and Interface |
Voltage Drive; Standard IGBT Gate Driver Chips Suffice |
