ABB 89AR30 GKWN000326R0100
| Brand | ABB |
| Module Number | 89AR30 |
| Order Number | GKWN000326R0100 |
| Unit price | $1999 |
| Country Of Origin | Switzerland and Sweden |
| Weight | 1KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 5 |
ABB 89AR30 relay and signal control unit, Production by the original manufacturer has ceased; when sourcing spare parts, be sure to verify the status of the board’s relays, contact continuity, and insulation.
The 89AR301 is designed to receive 24 VDC logic control signals and provides outputs for protection tripping, alarm circuits, and interlocking signals. It features forcibly guided contacts, making it suitable for protection logic circuits in power plants.
The board is equipped with multiple SPDT (Single-Pole Double-Throw) changeover relays, enabling NO/NC switching outputs; channels are electrically isolated to suppress interference and crosstalk. It is commonly used in retrofit projects and spare part replacements for thermal and hydroelectric power plants.
Operational specifications are as follows:
Drive Power Supply: 24 VDC (logic power for the board)
Relay Type: SPDT (Form-C) forcibly guided safety contacts
Contact Rating: 5–10 A @ 250 VAC (resistive load); derating required for inductive loads
Operation Time: Pickup ≈ 10 ms, Dropout ≈ 5 ms; Electrical life ≥ 100,000 cycles (at rated resistive load)
Mechanical Life: ≥ 10 million cycles
Operating Temperature: -25°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5–95% RH (non-condensing)
Protection Rating: IP20 (for internal cabinet use)
