IOCR2 600-022-000-112
| Brand | VIBRO-METER MEGGITT |
| Module Number | IOCR2 620-022-000-112 |
| Unit price | $5999 |
| Country Of Origin | UK(Germany Switzerland) |
| Weight | 0.5KG |
| Warranty | 12 Months |
| Inventory Qty | 1 |
VIBRO-METER(Meggitt) IOCR2 600-022-000-112 is communication interface card and used with CPUR2 rack controller.
IOCR2 as an system controller and data communication gateway for MPS and CMS, Having the capabilities of on-site bus data processing and dual protocol redundant communication.
As for ordering information,620-022-000-VVV, vvv represent the different firmware versions or hardware versions that can be used by a finished product.
Introduction to Structural Configuration:
RJ45: 2 × Gigabit Ethernet (Modbus TCP / proprietary protocols)
PROFIBUS DP: 1 × D-sub 9-pin (fieldbus communication)
RS-485: 1 × D-sub (multi-drop network, rack-to-rack cascading)
Relay outputs: 5 × SPDT (Single-Pole Double-Throw), 250 VAC/30 VDC, 2 A
Required configuration software: VM600 MPSx (MPS1/MPS2), VibroSight®
Supported protocols: Modbus TCP (Master/Slave), PROFIBUS DP (Slave), Meggitt proprietary protocols
Data processing capabilities: Supports over 20 types of calculated outputs, including peak, RMS, peak-to-peak, rotational speed, and phase
