Rockwell Allen-Bradley 1440-SPD02-01RB
| Brand | Allen-Bradley |
| Model Number | 1440-SPD02-01RB |
| Unit price | $1999 |
| Country Of Origin | USA |
| Weight | 0.5KG |
| Certificate |
C/O from the Chamber of Commerce C/Q from the Manufacturer |
| Warranty | 12 Months |
| Inventory Qty | 1 |
Allen-Bradley 1440-SPD02-01RB is XM-220 DUAL SPEED MODULE, it measures speed, rotor acceleration and peak speed.
|
Parameter |
Specification |
|
Inputs(two tachometer inputs) |
±25V (50V max peak-to-peak) Eddy current transducer signals Magnetic pickups TTL output devices |
|
Outputs(4…20 mA outputs) |
Each output is independently programmed to represent speed or acceleration, from either channel Two isolated outputs 300 Ω max load One active buffer per input channel |
|
Communication(DeviceNet network) |
Standard DeviceNet protocol for all functions (not power—module power is provided independently) Available EDS file provides support for most DeviceNet compliant systems Communication rate automatically set by bus master to 125, 250, or 500 Kbps Configurable I/O Poll Response message helps optimize space utilization within scanner input tables: Selectable poll response assembly Selectable poll response size (bytes) |
|
Environmental(Temperature, storage) |
-40…85 °C (-40…185 °F) |
Account Number 88800006406771
Account name Vogi International Trading Co., Limited
(* If the account name exceeds the available space, please continue in the address field.)
SWITF/BIC Code WIHBHKHHXXX
Bank name OCBC Hong Kong Branch
Bank address 161 Queen's Road Central, Central, Hong Kong
Country/Region Hong Kong (China)
Account type Business Account
Bank code 035
Payment method For the payment of goods, please make a FPS/CHATS/SWIFT Payment
Notes Please include the following memo/message to receiver when making a payment: [Buyer Name] [Invoice/Contract Number] [Product]
Key Features
The measurement range is extremely wide (1 - 1,200,000 rpm), and the accuracy is as high as ±0.2 rpm in the low-speed range (such as 1 - 240 rpm). It supports multiple sensor inputs including eddy current probes, magnetoelectric, and TTL signals.
It offers three working modes: independent dual-channel, single-channel redundancy, and reverse detection mode. It comes with one DPDT relay and is expandable; it provides two isolated 4-20mA analog output channels, which can be programmed to correspond to speed or acceleration values.
Supports DeviceNet network communication (125/250/500 Kbps), facilitating integration into automation systems; meanwhile, retains the RS-232 serial port for local configuration. All configurations are saved in non-volatile memory.
